Panel Air Filter for Coarse Filtration
Model | Overall Dimensions (mm) | Rated Airflow (m³/h) | Initial Resistance (Pa) | Efficiency (Class) |
CG-8 | 295×295×45(mm) | 800 |
25-45 |
≤50% (Gravimetric Method) |
G1-G4 |
CG-13 | 490×295×45(mm) | 1300 |
CG-22 | 490×490×45(mm) | 2200 |
CG-16 | 595×295×45(mm) | 1600 |
CG-27 | 595×490×45(mm) | 2700 |
CG-32 | 595×595×45(mm) | 3200 |
Filters in various specifications and models can be customized according to user requirements.
Ultra-Thin Air Filter for Coarse Filtration
Model | Overall Dimensions (mm) | Rated Airflow (m³/h) | Initial Resistance (Pa) | Efficiency (Class) |
|
CCB-8 | 295×295×10(mm) | 800 |
25 |
40% (Gravimetric Method) |
G1 |
CCB-13 | 490×295×10(mm) | 1300 |
CCB-22 | 490×490×10(mm) | 2200 |
CCB-16 | 595×295×10(mm) | 1600 |
CCB-27 | 595×490×10(mm) | 2700 |
CCB-32 | 595×595×10(mm) | 3200 |
|
Filters in various specifications and models can be customized according to user requirements.
Cardboard-Frame Air Filter for Coarse Filtration
Model | Overall Dimensions (mm) | Rated Airflow (m³/h) | Initial Resistance (Pa) | Efficiency (Class) |
CY-8Z | 295×295×25 12"×12"×1" | 800 |
24 |
50% (Gravimetric Method) |
G1 |
CY-13Z | 490×295×25 20"×21"×1" | 1300 |
CY-22Z | 490×490×25 20"×20"×1" | 2200 |
CY-16Z | 595×295×25 24"×12"×1" | 1600 |
CY-27Z | 595×490×25 24"×20"×1" | 2700 |
CY-32Z | 595×595×25 24"×24"×1" | 3200 |
Filters in various specifications and models can be customized according to user requirements.
Nylon Mesh Air Filter for Coarse Filtration
Model | Overall Dimensions (mm) | Airflow (m³/h) | Initial Resistance (Pa) |
CNL-16 | 595×295×10(mm) 24"×12"×1/2" | 1600 |
≤15 |
CNL-22 | 490×490×10(mm) 20"×20"×1/2" | 2200 |
CNL-32 | 595×595×10(mm) 24"×24"×1/2" | 3200 |
Filters in various specifications and models can be customized according to user requirements.
F5/F6 Medium-Efficiency Bag Air Filter
Model | Overall Dimensions (mm) | Rated Airflow (m³/h) | Initial Resistance | Efficiency (Class) | Number of Bags |
ZF5(6)-13 | 490×295×600 | 1300 |
50PaF5
55PaF6 |
40-45% F5 (Particle Counting Method)
60-70% F6 (Particle Counting Method) | 5 |
|
ZF5(6)-22 | 490×490×600 | 2200 | 5 |
ZF5(6)-16 | 595×295×600 | 1600 | 6 |
ZF5(6)-27 | 595×490×600 | 2700 | 6 |
ZF5(6)-32 | 595×595×600 | 3200 | 8 |
Filters in various specifications and models can be customized according to user requirements.
F7/F8 Medium-Efficiency Bag Air Filter
Model | Overall Dimensions (mm) | Rated Airflow (m³/h) | Initial Resistance | Efficiency (Class) | Number of Bags |
ZF7(8)-13 | 490×295×600 | 1300 |
95PaF7
100PaF8 |
80-85% F7 (Particle Counting Method)
90-95% F8 (Particle Counting Method) | 8 |
ZF7(8)-22 | 490×490×600 | 2200 | 8 |
ZF7(8)-16 | 595×295×600 | 1600 | 10 |
ZF7(8)-27 | 595×490×600 | 2700 | 10 |
ZF7(8)-32 | 595×595×600 | 3200 | 10 |
Filters in various specifications and models can be customized according to user requirements.
F9 Medium-Efficiency Bag Air Filter
Model | Overall Dimensions (mm) | Rated Airflow (m³/h) | Initial Resistance (Pa) | Efficiency (Class) | Number of Bags |
ZF9-13 | 490×295×600 | 1300 |
120 |
98% (Particle Counting Method) |
F9 | 4 |
ZF9-22 | 490×490×600 | 2200 | 4 |
ZF9-16 | 595×295×600 | 1600 | 6 |
ZF9-27 | 595×490×600 | 2700 | 8 |
ZF9-32 | 595×595×600 | 3200 | 10 |
Filters in various specifications and models can be customized according to user requirements.
ZZH Medium-Efficiency Combination Air Filter
Model | Overall Dimensions (mm) | Rated Airflow (m³/h) | Initial Resistance | Efficiency (Class) |
ZZH-36 |
592×592×295 |
3600 |
≤120Pa(F7) |
60-50% F6 80-85% F7 90-95% F8 >90% F9 |
ZZH-18 |
295×592×295 |
1800 |
Filters in various specifications and models can be customized according to user requirements.
GNGS High-Efficiency Air Filter for High-Humidity Environments
Suitable for use in environments with 100% RH |
|
Model / Item | GNGS-3 | GNGS-5 | GNGS-8 | GNGS-12 | GNGS-15 |
Overall Dimensions (mm) | 305×610×150 | 460×610×150 | 610×610×150 | 820×610×150 | 915×610×150 |
Rated Airflow (m³/h) | 300 | 550 | 800 | 1200 | 1500 |
Weight (kg) | ≈5 | ≈8 | ≈10 | ≈13 | ≈15 |
Dust-Holding Capacity (g) | 300 | 450 | 600 | 750 | 850 |
Efficiency (Sodium Flame Method) | ≥99.99% |
Initial Resistance | ≤220Pa(22.4mmH₂O) |
We accept orders for GNGS filters in special specifications.
GGZH High-Efficiency Combination Air Filter
Model | Overall Dimensions (W×H×D)(mm) | Rated Airflow (m³/h) | Initial Resistance (pa) | Efficiency (MPPS) | Weight (kg) |
|
GGZH-10 | 295×595×295 | 1000 |
≤250 |
≥99.99% | 4 |
GGZH-15 | 390×595×295 | 1500 | 6 |
GGZH-21 | 490×595×295 | 2100 | 8 |
GGZH-27 | 595×595×295 | 2700 | 10 |
GGZH-33 | 610×610×295 | 3300 | 12 |
*We accept orders for GGZH filters in special specifications.
High-Volume Activated Carbon Filter
Type | Standard Dimensions L×W×D mm | Rated Airflow m³/h | Filtration Area m² | Initial Resistance Pa |
HTD-A |
592×592×292 |
3200 |
7,3 |
120 |
HTD-B |
592×490×292 |
2400 |
4,7 |
120 |
HTD-C |
592×287×292 |
1600 |
3,5 |
120 |
Panel Activated Carbon Filter
Our panel activated carbon filters are manufactured to customer specifications. Please contact us for more information.
